| Item |
Specifications |
| Product Number |
FT-E13 |
| Part Number |
FT-E13 |
| Sensing mode |
Thru-beam type |
| Fiber type |
Sleeve type Ultra-small diameter |
| Fiber head dia. |
dia. 3 mm |
| Fiber head length |
15 mm |
| With sleeve |
Yes |
| Sleeve dia. |
dia. 0.25 mm |
| Sleeve length |
5 mm |
| Beam direction |
Top-view |
| Beam axis dia./ Spot diameter |
dia. 0.125 mm |
| Fiber cable length |
1 m |
| Allowable bending radius |
R2 mm |
| Free-cut |
Available |
| Mounting lens |
Not available |
| Mounting protective tube |
Not available |
| Application |
General-purpose |
| Environmental resistance : Protection |
IP67 |
| Environmental resistance : Ambient temperature MAX |
70 degrees |
| Environmental resistance : Ambient temperature MIN |
-40 degrees |
| Sensing range（STD） |
15 mm 0.591 in (FX-500 series) |
| Sensing range（HYPR） |
52 mm 2.047 in (FX-500 series) |
| Sensing range（U-LG） |
30 mm 1.181 in (FX-500 series) |
| Sensing range（LONG） |
24 mm 0.945 in (FX-500 series) |
| Sensing range（FAST） |
8 mm 0.315 in (FX-500 series) |
| Sensing range（H-SP） |
2 mm 0.079 in (FX-500 series) |
