| Item |
Specifications |
| Product Number |
FT-V23 |
| Part Number |
FT-V23 |
| Sensing mode |
Thru-beam type |
| Fiber type |
Sleeve type |
| Fiber head dia. |
dia. 2 mm |
| Fiber head length |
15 mm |
| With sleeve |
Yes |
| Sleeve dia. |
dia. 1 mm |
| Sleeve length |
20 mm |
| Beam direction |
Side-view |
| Beam axis dia./ Spot diameter |
dia. 0.75 mm |
| Fiber cable length |
2 m |
| Allowable bending radius |
R4 mm |
| Free-cut |
Available |
| Mounting lens |
Not available |
| Mounting protective tube |
Not available |
| Application |
General-purpose |
| Environmental resistance : Protection |
IP30 |
| Environmental resistance : Ambient temperature MAX |
80 degrees |
| Environmental resistance : Ambient temperature MIN |
-55 degrees |
| Sensing range（STD） |
450 mm 17.717 in (FX-500 series) |
| Sensing range（HYPR） |
1,800 mm 70.866 in (FX-500 series) |
| Sensing range（U-LG） |
1,000 mm 39.370 in (FX-500 series) |
| Sensing range（LONG） |
880 mm 34.646 in (FX-500 series) |
| Sensing range（FAST） |
280 mm 11.024 in (FX-500 series) |
| Sensing range（H-SP） |
90 mm 3.543 in (FX-500 series) |
