Specifications
Primary brand: Turck
Main function: Sensor (Proximity; inductive)
Product series / family name
Sensors > Inductive sensors
Sub-range name: NI...-Q18 series
Functions: Inductive proximity sensor / switch
Supply voltage (DC): 10-30Vdc (12Vdc / 24Vdc nom.)
Sensing distance: 5mm
Display: LED indicator
Shape: 18mm thick rectangular body
Connection type: Pre-wired with 20cm / 8" pigtail cable terminated with 3-pin M8 Picofast threaded coupl. nut male connector
Protection functions: Short-circuit (pulsed)
Overload: Reverse polarity
Operating mode: NO (Normally Open)
Digital outputs: 1 x digital output (10-30Vdc; PNP)
Degree of protection: IP67
Material: PBT (Polybutylene Terephthalate) housing
PBT-GF30-V0 (glass fb. reinforced Polybutylene Terephthalate) sensing face
Ambient air temperature for operation: -25°C...+70 °C
