| Operation method |
Time setting |
| Output Operation |
POWER ON DELAY, FLICKER, INTERVAL |
| Time operation |
POWER ON START |
| Terminal |
8-pin plug |
| Power supply |
100-240VAC~50/60Hz, 24-240VDC  |
| Setting range |
0.1 to 1 sec, 1 to 10 sec, 0.1 to 1 min, 1 to 10 min, 0.1 to 1 hour, 1 to 10 hour |
| Control output |
Time-limit DPDT (1c): 2 or Instantaneous SPDT (1c): 1 + Time-limit SPDT (1c): 1 depending on output operation mode |
| Accessories |
Bracket |
| Environment_Ambient temperature |
-10 to 55℃, storage: -25 to 65℃ |
| Environment_Ambient humidity |
35 to 85%RH |
| Weight |
Approx. 95g (approx. 70g) |
