ĐẶC ĐIỂM NỔI BẬT
Type
Standard type(bolt type)
Sensing distance
110mm
Min. sensing target
Ø0.3mm
Allowable bend radius
R5
Cable length
2m
Free cut
Free cut
Adapter
Adapter
Environment_Ambient temperature
-40 to 60℃
Sensing type
Through-beam type
※The sensing distance is a standard for BF5 Series.
※Min. sensing target is a value measured opaque material in accurate output status and the sensing distance is different with the rated sensing distance.
※Flexible optical fiber (Multi core): A large number of ultra-fine cores are all surrounded by cladding. Easy to install it in the many places as the change of the intensity of radiation by bending is small.
Break-resistant optical fiber: The fiber units contain a large number of independent fine fibers, by ensuring a high degree of flexibility. It can be used for moving parts (robot hand) and it is not easily broken.
※Free cut type's sensing distance can be shortened about max. 20% than the normal according to condition of the cable. [(FC-3) should be used for cutting fiber cable.]
※FT-420-13 was discontinued. FT-420-13B is replacement.
※Glass type is for BF5, BF4 Series.
