| Item |
Specifications |
| Product Number |
FT-V25 |
| Part Number |
FT-V25 |
| Sensing mode |
Thru-beam type |
| Fiber type |
Sleeve type |
| Fiber head dia. |
dia. 2 mm |
| Fiber head length |
15 mm |
| With sleeve |
Yes |
| Sleeve dia. |
dia. 1 mm |
| Sleeve length |
15 mm |
| Beam direction |
Side-view |
| Beam axis dia./ Spot diameter |
dia. 0.5 mm |
| Fiber cable length |
2 m |
| Allowable bending radius |
R2 mm |
| Free-cut |
Available |
| Mounting lens |
Not available |
| Mounting protective tube |
Not available |
| Application |
General-purpose |
| Environmental resistance : Protection |
IP30 |
| Environmental resistance : Ambient temperature MAX |
80 degrees |
| Environmental resistance : Ambient temperature MIN |
-55 degrees |
| Sensing range（STD） |
240 mm 9.449 in (FX-500 series) |
| Sensing range（HYPR） |
900 mm 35.433 in (FX-500 series) |
| Sensing range（U-LG） |
550 mm 21.654 in (FX-500 series) |
| Sensing range（LONG） |
480 mm 18.898 in (FX-500 series) |
| Sensing range（FAST） |
140 mm 5.512 in (FX-500 series) |
| Sensing range（H-SP） |
45 mm 1.772 in (FX-500 series) |
