| Technical data | KL9210 |
|---|---|
| Nominal voltage | 24 V DC |
| Current load | ≤ 10 A |
| Integrated fine-wire fuse | …6.3 A |
| Diagnostics | yes |
| Power LED | green |
| Defect LED | red |
| Reported to K-bus | yes |
| PE contact | yes |
| Shield connection | – |
| Renewed infeed | – |
| Connection facility to additional power contact | 1 |
| K-bus, looped through | yes |
| Bit width in the process image | 2 |
| Electrical connection to DIN rail | – |
| Current consumption K-bus | typ. 10 mA |
| Electrical isolation | yes |
| Housing width | 12 mm |
| Special features | integrated fuse |
| Weight | approx. 55 g |
| Side by side mounting on Bus Terminals with power contact | yes |
| Side by side mounting on Bus Terminals without power contact | yes |
| Operating/storage temperature | -25…+60 °C/-40…+85 °C |
| Approvals/markings | CE, UL, ATEX, IECEx, DNV GL |
| Ex marking | ATEX: II 3 G Ex nA IIC T4 Gc IECEx: Ex ec IIC T4 Gc |
