AJ65BT-64AD Specifications
| Analog Input Points | 4 points (4 channels) | ||
|---|---|---|---|
| Analog Input | Voltage | -10 to +10 V DC (input resistance: 11 MΩ) | |
| Current | -20 to +20 mA DC (input resistance: 250 Ω) | ||
| Digital Output | 0 to 4,000, -2,000 to +2,000 | ||
| Input/Output Characteristics, Resolution | Input Range | Digital Output Value (Maximum Resolution) | |
| Voltage Input | -10 To 10 V | 0 to 4,000 or -2,000 to 2,000 (5 mV) | |
| 0 To 10 V | 0 to 4,000 or -2,000 to 2,000 (2.5 mV) | ||
| 0 To 5 V | 0 to 4,000 or -2,000 to 2,000 (1.25 mV) | ||
| 1 To 5 V | 0 to 4,000 or -2,000 to 2,000 (1.0 mV) | ||
| Current Input | -20 To 20 mA | 0 to 4,000 or -2,000 to 2,000 (20 μA) | |
| 0 To 20 mA | 0 to 4,000 or -2,000 to 2,000 (10 μA / 5 μA) | ||
| 4 To 20 mA | 0 to 4,000 or -2,000 to 2,000 (4 μA) | ||
| Precision (Precision With Respect To Maximum Digital Output Value) | Ambient Temperature: 0 To 55°C | ±1% | |
| A/D Conversion Speed | 1 ms/channel | ||
| Absolute Maximum Input | Voltage | ±15 V | |
| Current | ±30 mA | ||
| Isolation Method | Between power supply / communication system and analog input: photocoupler insulation Between channels: non-insulation |
||
| Dielectric Strength | Between power supply / communication system at once and all analog inputs at once: 500 V AC for 1 minute | ||
| Insulation Resistance | Between all power supply / communication systems at once and all analog inputs at once: 10 MΩ or more at 500 V DC on an insulation resistance meter | ||
| Station Type | Remote Device Station (Ver. 1 Remote Device Station) | ||
| Number Of Occupied Stations | 2 stations | ||
| Unit Power Supply | Voltage | 24 V DC (18 to 30 V DC) | |
| Current | 0.12 A (at 24 V DC) | ||
| External Wiring Connection Method | Communication part, unit power supply part: 7-point 2-piece terminal block (M3.5 screw) Input/output part: 27-point 2-piece terminal block (M3.5 screw) |
||
| External Dimensions | Height (H) | 65 mm | |
| Width (W) | 151.9 mm | ||
| Depth (D) | 63 mm | ||
| Mass | 0.35 kg | ||
