| Type | RSS110060 | |
|---|---|---|
| Coil nominal voltage | 60 V DC | |
| Max. pick-up voltage | 42 V DC | |
| Resistance (coil) | 20570 Ω | |
| Contact type | 1 change-over | |
| Contact material | AgSnO | |
| Switching voltage (max.) | 250 V DC/AC | |
| Max. switching capacity | 1500 VA, 144 W | |
| Creepage distance (coil/clips) | 5.5 mm | |
| Connection | Connector | |
| Response time | 8 ms | |
| Fall time | 4 ms | |
| Features | w/o test button | |
| IP rating | IP67 | |
| Min. temperature | -40 °C | |
| Max. temperature | +85 °C | |
| Weight | 5 g | |
| Factory colour | White | |
| Width | 5 mm | |
| Height | 28 mm | |
| Depth | 15 mm | |
| Dim | (W x H x D) 5 x 28 x 15 mm | |
| Content | 20 pc(s) | |
| Product type | Relay |
